Audiotechnika Ortofon Concorde Made From Scratch Twin

Ortofon Concorde Made From Scratch Twin

Output voltage at 1000Hz, 5cm/sec. - 7 mV Channel balance at 1kHz - 1,5 dB Channel separation at 1kHz - 25 dB Channel separation at 15 kHz - 15 dB Frequency range at -3dB - 20-20.000 Hz Frequency response - 20-15.000 Hz 3dB/-2dB Tracking ability at 315 Hz at recommmende tracking force - 80 μm Compliance, dynamic lateral - 6 &mu...

Bővebben ID: 282865 EAN: 5705796031591

Legjobb ár garancia

Ha ezt a terméket máshol olcsóbban találod, mi megtérítjük a különbözetet!
bővebben

Állapot

Új

Elérhetőség

1 hét

Ár

93 690 Ft Ingyenes szállítás

Elérhetőség

1 hét

Output voltage at 1000Hz, 5cm/sec. - 7 mV
Channel balance at 1kHz - 1,5 dB
Channel separation at 1kHz - 25 dB
Channel separation at 15 kHz - 15 dB
Frequency range at -3dB - 20-20.000 Hz
Frequency response - 20-15.000 Hz 3dB/-2dB
Tracking ability at 315 Hz at recommmende tracking force - 80 μm
Compliance, dynamic lateral - 6 μm/m N
Stylus type - Spherical
Stylus tip radius - R 18 μm
Tracking force range - 3,0-5,0 g (30-50 mN)
Tracking force recommended - 4,0 g (40 mN)

Tracking angle - 20°
Internal impedance, DC resistance - 750 Ohm
Internal inductance - 450 mH
Recommended load resistance - 47 kOhm
Recommended load capacitance - 200-600 pF
Cartridge weight - 18,5 g

Replacement stylus unit - Made From Scratch
